Plate Feeder / Plate Feeding Machine / Apron Feeder
Our plate feeders are designed to consistently, smoothly deliver materials, such as rocks, sand, gravel, ore or powder, from storage or hoppers to downstream processing equipment like crushers, conveyors, or screens. The feeders are widely used in metallurgy, coal, mineral processing, construction materials, chemicals, aggregates, etc.
Working Principle
The feeder operates by generating centrifugal force through the rotation of eccentric blocks inside the vibrator. This force drives the screen box, vibrator into a continuous circular or near-circular motion.
The materials placed on the inclined surface the feeder are forced to moved forward to downstream processing equipment consistently and uniformly.
Your Benefits
Less footprint, less weight with simple rational structure
Easy installation, low maintenance
High efficiency, large capacity
Low noise, better working environment
Less power consumption, higher power factor
Stable and reliable performance, strong adaptability allowing it to handle a wide range of material types effectively.
Enclosed housing design (optional), for enhanced dust proof and improved working conditions
Custom-engineered solutions to match your exact process.
Technical information
Model | Screen Size (mm) | Inclined Angle | Vibrating Frequency (rpm) | Feeding Size (mm) | Capacity (t/h) | Motor Power (kw) | Wight (kg) |
HXGA1020 | 1000*2000 | 15 | 350-975 | ≤600 | 200-300 | 11 | 1950 |
HXGA1220 | 1200*2000 | 15 | 350-975 | ≤800 | 250-400 | 11 | 2050 |
HXGA1420 | 1400*2000 | 15 | 350-975 | ≤1000 | 350-500 | 15 | 2570 |
HXGA1530 | 1500*3000 | 12 | 350-975 | ≤1000 | 350-500 | 15 | 3360 |
All parameters are for reference only & subject to change without notice.
Note: The table displays only a partial list of our product models. For additional models or customized solutions, please contact us directly.
