Spiral Sand Washer / Screw Sand Washer
The spiral sand washer is a specialized sand washing machine commonly used in mining, quarrying, and sand production plants. It is designed with an internal spiral mechanism that stirs and agitates sand and gravel, efficiently separating mud, clay, and other impurities to produce clean, high-quality materials.
Key Features
Optimized Design
Smart, well-engineered structure ensures smooth operation and easy maintenance.
High Throughput, Low Power Consumption
Handles large material volumes while minimizing power consumption for greater efficiency.
Superior Cleaning & Dewatering Performance
Delivers outstanding washing and dehydration performance, guaranteeing consistently clean high-quality output.
Robust and Durable
Features a robust well-sealed structure and fully enclosed transmission system for long-lasting, reliable performance.
Consistent Fine Material Recovery
Effectively retains fine particles, ensuring product consistency and quality.
Technical Specifications
Model | Screw Diameter (mm) | Sink Length (mm) | Sink Inclined Angle | Feeding Size (mm) | Capacity (t/h) | Speed of Screw (r/min) | Motor Power (kw) | Weight (kg) |
HXLS1270 | 1200 | 7000 | 20 | ≤10 | 40-120 | 6-9 | 11 | 5500 |
HXLS1570 | 1500 | 7000 | 20 | ≤10 | 50-150 | 6-9 | 15 | 6200 |
2HXLS1270 | 1200 | 7000 | 20 | ≤10 | 70-200 | 9-11 | 2*11 | 7350 |
2HXLS1570 | 1500 | 7000 | 20 | ≤10 | 90-250 | 9-11 | 2*15 | 9000 |
All parameters are for reference only & subject to change without notice.
Note: The table displays only a partial list of our product models. For additional models or customized solutions, please contact us directly.
